Meticulously designed for industrial and commercial efficiency, representing top tier durability, high quality components, and peak output capability.
HIgh-visibility LED display
Shielded agalnst nolse (RFI,EMI)
High-speed A/D conversion (200 times/sec) & high display resolution (1/10,000)
Watch-dog & self-hardware test function
Weight back-up function
2 external relay Inputs & 3 external relay outputs
Terminal block Installed
By using DC power, Input power can be used In 12~24VDC regardless of polarity (300mA or over Is advisable)
Simple and prompt Full Digital Calibration
Equivalent Input mode for Calibration
Variety of applications
( Platform scale, Truck scale, checking scale, packing scale, tester etc)
Option : 12 or 24 VDC adapter
RS-422/485
Analog out(V-out: 0~10V, I-out: 4~20mA)
